2' Black RG58 Cable (SMA/Male & N/Male Connectors)

This 2' RG-58 cable has an N-Male connector on one side and an SMA-Male connector on the other.

This cable is typically used as a "jumper" cable to connect a splitter or lightning surge protector to an amplifier or antenna with an SMA/Female connector.

Specifications:

• Cable length: 2'
• Connectors: N/Male & SMA/Male
• Impedence: 50ohms
• N/Male connector diameter: 3/4"
• Cable diameter: 3/16"

Signal Loss:

• The amount of signal attenuation you'll see depends on which frequency you're using. This cable averages less than 0.5dB of signal loss. Attenuation for each frequency is below:

  • 700mhz: 0.3dB
  • 800mhz: 0.3dB
  • 1700mhz: 0.4dB
  • 1900mhz: 0.4dB
  • 2100mhz: 0.5dB
  • 2400mhz: 0.5dB
  • 2500mhz: 0.5dB
• Approximately .5dbm is lost at each connection between 2 cables
• To prevent excessive signal loss, this cable should NOT be daisy chained with other cables! It is always better to use one longer piece of cable than to screw two shorter cables together.
