SureCall 2G/3G M2M Direct Connect Amplifier - SC-SOLOI-15

SureCall 2G/3G Direct Connect M2M Amplifier w/ Mag Mount Antenna [800/1900mhz]


1 Customer Review 1 Questions
Call for Availability
Item Number: 5015
Model: SC-SOLOI-15
Quantity:
Have a large deployment?
Request a Quote

Price:

$200.00

Related Products
This is a special-order item that requires additional lead time. Contact us before ordering if you need a more exact ETA.

This amplifier includes a cable terminated in SMA/Male for use with most routers/modems - an adapter is required to use with other devices (hotspots, etc).

Amplifier features:

  • All-in-One Kit? NO - a 6" mag mount antenna is included, but most users opt to purchase a different antenna instead; users of non-SMA devices will need an adapter to connect the amp to their device (sold separately)
  • Compatibility: 800mhz/1900mhz networks, which are used by most 2G (voice) and 3G networks in the USA, including:
    • Verizon 2G/3G
    • Sprint 2G/3G
    • AT&T 2G/3G and HSPA+ (which shows up on your device as "4G" - NOT LTE)
    • T-Mobile and Cricket voice only
    • Does NOT work with LTE for any carrier or AWS (T-Mobile 3G/4G)
IMPORTANT SIGNAL INFORMATION: If you're purchasing an amplifier for use at one specific location, we strongly recommend doing a site survey first to determine whether the amplifier will help you and to give you an idea of what kind of results you can expect from it.

If your signal is extremely poor (-108db or worse), an amplifier may not be effective - there must be some usable signal available for the amplifier to boost. Conversely, if the signal is too STRONG at your location (-50db or better), the amplifier may shut down to avoid interference with the tower.

Are you stuck in a weak coverage area or traveling in a vehicle and want to improve your signal as much as possible? A good antenna is a must, but if you want the best possible signal, a direct connect signal amplifier is the answer. A direct connect signal amplifier plugs in between your external antenna and your mobile broadband device to provide the best possible signal wherever you are.

SureCall_M2M_2G_3G_Data_Sheet(5015).pdf
SureCall M2M - User Guide(5015).pdf



Features & Benefits:

  • Proven solution for over a decade
  • The first and only FCC Certified direct connect solution to date
  • Compact in size and designed for excellent heat dissipation
  • Quality metal construction is durable and resilient
  • Supports all 2G and 3G standards
  • FCC certified for new regulagtions and technical standards
  • Stealth technology incorporated – uplink becomes dormant when not in use, providing green, power saving operation
  • Easy to install plug and play

Package Includes:

  • SC-SOLOI-15 15 dB direct-connect amplifier
  • 6" CM200-S 3dB magnetic mount antenna (must be mounted to something magnetic with 9.75' cable attached.
  • CN-CM-CN-06 SMA/Male to FME/Male adapter (for users who want to use an FME antenna instead of the included magnetic mount antenna)
  • 6' cable with SMA/Male and FME/Female connectors (to connect an adapter cable to the amplifier)
  • 6' cable with SMA/Male connectors on both sides (for M2M users - connect directly to your device's SMA connector without the need for an additional adapter)
  • AC Power Supply (DC power supply available separately)
  • Velcro and Screw Mounting Kit
  • User Manual

Specifications:

  • Frequency Range: Uplink: 824-849 and 1850-1910 MHz / Downlink: 869-894 and 1930-1990 MHz
  • Gain: 15dB
  • Max Output Power: 1 watt
  • Impedance: 50ohms
  • Noise Figure: Maximum 5 dB
  • VSWR: Less than 2:1
  • AC Power Transformer: Input: AC 100 – 240 V, 50 – 60 Hz / Output: DC 5–15 V
  • Antenna: Dual band magnetic antenna with maximum 3dBi directional gain included
  • RF Connectors: SMA/Female (SMA to FME adapters included)
  • Power Consumption: <10w
  • Dimensions: 4.7" x 2.7" x 0.98"
  • Weight: 0.57lb
  • FCC ID: RSNM2M
This is a CONSUMER device.
BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and have your provider's consent. Most wireless providers consent to the use of signal boosters. Some providers may not consent to the use of this device on their network. If you are unsure, contact your provider.
You MUST operate this device with approved antennas and cables as specified by the manufacturer. Antennas MUST be installed at least 20 cm (8 inches) from any person.
You MUST cease operating this device immediately if requested by the FCC or a licensed wireless service provider.
WARNING. E911 location information may not be provided or may be inaccurate for calls served by using this device.
Please note, the four largest carriers - AT&T, T-Mobile, Verizon and Sprint - and more than 90 regional carriers have given blanket consent for use of all boosters certified to the new FCC standards.

Filter Reviews
   Last 2 Weeks (0)
    100% (1)
    0% (0)
    0% (0)
    0% (0)
    0% (0)

  Show Brief Review
  Show 5Gstore Comments
 Last 6 Months (0)
All Reviews (1)


Only customers who bought this item from 5Gstore can write a review - these are all verified 5Gstore purchases

Date Added: 06/20/2014 by Jamyl A. (Carolina, PR)
Good and reliable product.

If you purchased this item, Login to write a review.
Q & A
Got questions about this product? Here you can view questions that other customers have asked (and the answers!). If you have a question that hasn't been answered below, you may submit a new question and 5Gstore will answer it!


Click here to submit a new question
Sort By:

Will the SureCall amplifier (SC-SOLOI-15) work with the AT&T HSPA+ network?

Yes! HSPA+ is an extension of 3G technology and runs on the same networks and frequencies. This amplifier supports: Verizon 2G/3G Sprint 2G/3G AT&T 2G/3G and HSPA+ (which shows up on your device as "4G" - NOT LTE) Datajack and Virgin Mobile 3G T-Mobile and Cricket 2G.
